We bring end-to-end GPS jamming protection solutions for drone, fleet and critical infrastructure assets.

  • GPSDome

    Lightest

    74 x 47 x 25 mm.
    Weighing only 150g.

    Minimal Power Consumption

    Nominal power consumption <1W

    Compatible

    Compatible with any off-the-shelf active GNSS antenna and receiver. Fits on a variety of platforms.

GPSdome

Industry’s most disruptive C-SWaP GPS Anti-Jammer tailored for UAVs

Description

GPSdome is a small-sized (tailored for class 1-3 drones), retrofit module (compatible with any GNSS based receivers) that provides protection against GPS jamming, ensuring continuity of autonomous navigation and operation under GPS challenged conditions. GPSdome protects GPS L1 and at its minimal size weight and power there is no other solution that offers such protection is as small, light, affordable or as easily installed as GPSdome.

Features

Small sized

74 x 47 x 25 mm. (OEM 40mm x 65mm x 11mm.)

Light weight

150 gr. (OEM 35 gr.)

Safe and compliant

IP67 Waterproof rating
Auotomative temperature grade compliant -40 to +85 CE and FCC compliant

Protect

GPS L1 C/A Code

Power Consumption

< 1W

Passthrough frequencies

GPS L2 & Glonass G1

Latency

100ns +/- 15ns (fixed)

Insertion loss

+/- 2dB

Null steering algorithm

With proprietary signal filtering technology

Find out how we can help

Reach out to protect your assets
